Buddy B-210
Buddy B-210 is especially designed for home and small office. It enables 4 additional users to share the computing power and resources of a single computer running Win95/98.
Each user has their own Windows desktop, unique network login.
Buddy B-210 works with standard, off-the-shelf Win95/98.
S P E C I F I C A T I O N S
Buddy Controller Card Specification | |
Bus Interface: | PCI bus V2.1: 5V, 32bit, 33MHz |
Data Transfer Rate: | Up to 132MB/sec |
Video Driver Interface: | Compatible with Trident's RAM BIOS and Win95/98 Driver |
Communications Cable: | Category 5, standard ethernet pin out, with RJ-45 connectors |
Max. Controllers: | Four Buddy controller cards supported (depends on available PCI slots) |
Dimensions: | 6.5" x 4.0" (16.5cm x 10.1cm) |
Hardware Layout: | Single-sided |
Weight: | 3oz |
Power Consumption: | 7W (includes power required for controller card and junction box) |
DIP Switch: | 1 x 2-switch DIP switch bank to accommodate different motherboard initialization event counts. (0,4,8,64 counts) |
Agency Approval: | FCC Class B, CE |
Video Specifications | |
Video Chip: | Trident 3D image T9750 graphics chip This is a 2D/3D graphics accelerator chip. |
4MB of SGRAM: | Supports 1280 x 1204 x 16bit colours at 60Hz (true colour) Supports 1024 x 768 x 32bit colours at 75Hz (true colour) Supports 800 x 600 x 32bit colours at 85Hz (true colour) Supports 640 x 480 x 32bit colour at 85Hz (true colour) |
Buddy Junction Box Specifications | |
Transmission Distance: | 50ft maximum |
Transmission Medium: | CAT-5 (shielded, twisted pair with RJ-45 connectors) |
Dimensions: | 3.35" x 1.38" x 5.12" (8.5 x 3.5 x 13.0cm) |
Power of Peripherals: | 0.1A (maximum) |
Weight: | Less than 1lb |
Agency Approval: | FCC class B, CE |
Miscellaneous: | Contains 1 LED for system status monitoring Contains 1 buzzer for audible error detection and system initialization monitoring |
Peripherals Requirements | |
Monitor: | Super VGA HD15 female connector |
Keyboard: | Mini-DIN connector |
Mouse: | Mini-DIN connector |
Cable: | Communication signal port (RJ45/ethernet pin-out) |
